    Water Quality Digital Chlorophyll controller Fluorescence Method

    Ask Lasest Price
    Brand Name : Daruifuno
    Model Number : DUC2-CHL
    Certification : CE
    Price : Negotiable
    • Product Details
    • Company Profile

    Water Quality Digital Chlorophyll controller Fluorescence Method


    Water Quality Digital Chlorophyll controller Fluorescence method


    Brief Introduction


    1. Chlorophyll is the main lipid-soluble pigment for photosynthesis in plants and it plays a central role in light absorption for photosynthesis. Chlorophyll is contained in all photosynthetic organs. Also, chlorophyll a is one of the criteria used to measure the water quality and evaluate the eutrophication level of water bodies.


    2. The DUC chlorophyll analyzer is a single-parameter controller used for the measurement of chlorophyll in water. Each analyzer will be pre-installed with a set of embedded software to adapt to different chlorophyll digital sensors.


    3. The CHL meter is equipped witha two-wire RS485 interface, the communication protocol is MODBUS RTU, and supports JSON text data format. RS485 Modbus RTU provides a stable and reliable communication solution suitable for industrial environments, enabling different types of equipment to communicate and control each other, which is beneficial to the integration and management of industrial automation systems.


    4. This CHL analyzer can simultaneously meet the needs of users for detection, control, and remote data transmission, with rich output settings.


    Advantages Of The Chlorophyll Analyzer


    • Through the DUC2-CHL series general-purpose controller, users can query related information such as the working status and serial number of the connected sensor.

    • The CHL controller has a clock function and a historical data recording function, which can record 14,000 historical data, and the recording interval can be set between 1 and 999 minutes.
    • Its menu password can be set to facilitate user's data confidentiality.

    • The shell material of the instrument is reinforced ABS, the shell is strong, corrosion-resistant, and wear-resistant.

    • The user can choose a variety of installation methods such as wall-mounted installation, pipe clamping installation, and panel installation.

    • The CHL meter has power-off protection configuration, and the parameters can be kept indefinitely.

    Technical Parameters


    Product Name

    Chlorophyll Analyzer

    Product Model

    DUC2-CHL

    Software Version

    DRFN CHL Analysis software V1.0

    Display Range

    0 - 500ug or 0 - 100RFU

    Resolution

    0.01 ug/L

    Relay Control

    2 settable SPST relays max. load 3A/250VAC

    Analog Current Output

    2 settable 0/4~20mA active current loop output max. load 1000Ω

    Communication Method

    Two-wire RS485 interface; MODBUS RTU; support JSON text data format

    Display Screen

    128*64 LCD

    Time History/Data Record

    Year/month/day/hour/min/second, record 14000 historical data

    Protection Level

    IP66

    Operating Environment

    0~60℃, relative humidity less than 95% (no condensation)

    Storage Environment

    -20~70℃, relative humidity less than 55% (no condensation)

    Shell Material

    Enhanced ABS

    Size

    144*144*120mm (hole size 138*138 mm)

    Mounting Method

    Wall mounting, pipe clamping, panel mounting

    Power Supply

    100-240V AC (DC18~36V)

    Weight

    800g

    Power Consumption

    7W

    Applications Of The Chlorophyll Analyzer


    1. For online chlorophyll monitoring of water plant imports, drinking water sources, aquaculture, etc.


    2. Online monitoring of chlorophyll in different water bodies such as surface water, landscape water, and seawater.


    More Pictures About The Chlorophyll Analyzer
