    -10 ~ 150℃ Two SPST Relays Online PH ORP Analyzer For Water Quality Control

    Ask Lasest Price
    Brand Name : Daruifuno
    Model Number : APX1-G2A
    Certification :
    Price : Negotiable
    Payment Terms :
    Supply Ability : 100 Unit/Week
    Delivery Time : 7-10 Working Days
    • Product Details
    • Company Profile

    -10 ~ 150℃ Two SPST Relays Online PH ORP Analyzer For Water Quality Control


    -10~150℃ Two SPST Relays Online PH ORP Analyzer With Ground Electrode For Water Quality Control


    Brief introduction


    Differential signal PH/ORP on-line controller, more stable measurement, anti-interference ability;

    The user can set menu password, it is easy to manage hierarchically ;

    The online PH ORP analyzer has shortcut keys.It is easy to operate;

    The protective grade of the shell is IP66,that it can effectively isolate the pollution of the external environment and the invasion of corrosive gas.


    Applications of Online PH ORP analyzer


    1 Water treatment monitoring: drinking water,surface water,ground water,environmental sewage discharge monitoring,urban drainage network monitoring.


    2 Industrial process monitoring and dosing control treatment: chemical,petroleum,paper,food,medicine,electroplating,PCB manufacture.


    Technical Parameters of Online PH ORP analyzer


    ModelAPX1-G2A
    Software versionDRFN PH Analysis software V1.0
    Sensor Input PHGlass PH sensor.
    Sensor Input ORPRedox sensor (platinum / gold sensor)
    Sensor Input TEMPPT1000 or NTC10K

    Sensor Input

    Ground Electrode

    Combination electrode with ground rod
    Range/ Resolution PH-2~16pH / 0.01pH
    Range/ Resolution ORP±2000mV / 1mV

    Range/ Resolution

    Measure Temperature

    -10~150℃ / 0.1℃(14~302℉ / 0.1℉)
    Performance Accuracy0.1% of span or PH: ±0.02pH /ORP: ±2mV, select larger one.
    Performance Stability0.05% of span every 24 hours, no accumulation.

    Performance

    Repeatability

    Better than 0.1% of span
    Relay Control2 SPST relays: PH/OPR alarm, water temperature alarm, electrode cleaning cycle control; the maximum load is 3A/250VAC.
    Analog Current OutputTwo 0/4 ~ 20mA currents ; accuracy 0.00025 (16 bits); Maximum load 1000 Ω.
    Communication Mode

    Two-wire RS485 interface, communication protocol: MODBUS RTU

    Supports JSON (JavaScript Object Notation) text data formats.

    Display Language128 x 64 dots; English / Chinese / Other languages
    Working environmentOperating 0~60 ºC; storage -20~70 ºC; relative humidity < 95% RH (no condensation).
    Overall Dimensions100*100*120mm Panel hole dimension 92*92mm
    PowerAC power supply 100~240VAC
    Power Consumption3W
    Instrument WeightAbout 500g

    Advantage of Online PH ORP analyzer


    PH/ORP analyzer can be connected to a variety of traditional pH/T or ORP combination electrodes. It has the patented temperature detection and temperature drift compensation technology


    The PH/ORP online analyzer for differential signal input is compatible with ground rod pH sensors to solve problems like reference junction potential and sensor ground loops.


    The PH ORP analyzer is an online tester with rich output configuration, suitable for high-demand monitoring and control applications.


    More picture for Online PH ORP analyzer
